Description
This 80W Constant Power lab. grade power supply has an automatic range of 0.5-36V and 0-5A. The max. limits of current & voltage are calculated by Imax x Vmax = 80W. Its operation voltage and current spectrum is larger than 3 conventional power supplies of the same power rating. Adjustable upper voltage and current limits are necessary functions to protect sensitive devices against the wide swing of output current or voltage available. 3 user presets of V&I for frequently used output settings. Master & Slave configuration with SSP-9080 and SSP-9081 for parallel connection of multiple units up to 30 Units.
- Universal Input 100-264Vac, 50-60Hz
- Saves money and space as one power supply covers V, A limits of few power supplies.
- Auto range selection with maximum 80W output
- Support output Voltage range from 0.5 to 36V
- Support output Current range from 0 to 5A
- Adjustable upper voltage and current output levels to ensure safe operation
- 3 user presets of frequently used V and A outputs
- Master/Slave configuration for synchronization of the parallel connected output of multiple units.
- 4 digit display of voltage and current
- 10mV adjustment resolution for output Voltage
- 1mA adjustment resolution for output Current
- Output on-off switch and control panel lock button for safer operation
- Over Temperature, Over Current, Over Voltage and Short Circuit Protection
- Voltage remote sensing
